TOPCON Maestro2 Diagnostic System
Model: Maestro2
Ophthalmic diagnostic system that assesses the retina and optic nerve by combining optical coherence tomography (OCT) with true-color fundus photography.
TOPCON's Maestro2 pairs spectral-domain optical coherence tomography (SD-OCT) with a digital true-color fundus camera, producing detailed images of the retinal layers to help assess ocular conditions. Image capture is automated with a single touch, and the 3D wide scan covers up to 12 × 9 mm. The system also analyzes retinal thickness, the retinal nerve fiber layer and the ganglion cell layers. OCT Angiography (OCTA) can be added as an option, and anterior segment imaging requires a compatible optional attachment.
Request a quote
Key Features
OCT and Color Fundus Photography in One Device
Wide 12 × 9 mm Scan of Macula and Optic Disc
Fully Automatic Alignment and Capture
Hood Report for Glaucoma
Technical Specifications
| Specification | Details |
|---|---|
| Device Type | OCT Combined with Fundus Camera |
| Scan Speed | 50,000 A-scans per second |
| Lateral Resolution | 20 µm or less |
| In-Depth Resolution | 6 µm or less |
| Wide Scan | 12 × 9 mm (macula and optic disc) |
| Fundus Photography Angle | 45° |
| Color Imaging | White light, 24-bit color |
| Operation | Automatic alignment, focus and capture |
| OCT Angiography | OCTA via IMAGEnet 6 software |
| Analysis Reports | Hood Report for Glaucoma, retinal and optic disc analysis |
